Mosmatic 34.804 Nickel Plated Brass High Flow Swivel Rotary Union DGE - G1 3/4in. M x F, 4000 PSI, 30 RPM

Brand:
Mfr. Model #:
34.804
KR Part #:
SWM34804
Weight:
1.75 lbs
Usually Ships in 2 Weeks
MSRP
$256.34
Now Only!
$166.45
A swivel made with nickel plated brass. Used in automatic car wash systems. Tolerates a maximum pressure of 4000 PSI.



Technical Specifications

Max PSI: 4000
RPM: 30
Max Temperature: 250 degrees F
Outlet Port: 3/4 inch
Inlet Port: 3/4 inch

Product Description

High Flow Swivel

The Mosmatic 34.804 rotary union is designed to handle high flow rates and a maximum speed of 30 RPM. Constructed using brass with a nickel-plated coating and a stainless-steel inner part. Equipped with NBR seals. Handles a maximum pressure of 4000 PSI.

Specifications:

  • Pressure: 4000 PSI (27.5 MPa)
  • Temperature: 250°F
  • Max RPM: 30 RPM
  • Body: Nickel Plated Brass
  • Inner Part: Stainless Steel
  • Seal: O-ring (NBR)
  • Bearing: 1x Thrust Ball Bearing
  • Throughput: pH 3-12
  • Medium: Filtered 10 Microns, Compressed Air (290 PSI)

Applications:

  • High Flow
  • Low Rpm
  • Automatic Car Wash Systems
  • High Pressure Hose Reels

Dimensions:

  • G1 (F): G3/4_ F
  • G2 (M): R3/4_ M
  • NW: 18
  • SW1: 27
  • SW2: 40
  • L1: 88
  • L2: 60.5
  • L3: 16
  • D1: 50
