Norgren V61R517A-A313JB Solenoid Actuated/Spring Return Valve, 1/4 in. NPT, 24VDC, 5/2

Brand:
Mfr. Model #:
V61R517A-A313JB
KR Part #:
SK0405-24DC
Weight:
0.64 lbs
Usually Ships in 5 Weeks
MSRP
$144.09
Now Only!
$102.91

Norgren high flow rate 5/2 function direct control pilot valve. Manifold system features easy assembly. Low power consumption, extensive manual override options. It's a low power, high flow, maintenance free design with a fixed length manifold available.




Technical Specifications

Voltage DC: 24
Max PSI: 145
Max GPM: 1.3
Min Temperature: 14 F
Max Temperature: 122 F
Min PSI: 29

Product Description

Solenoid Actuated Spring Return Valve

Norgren Solenoid Actuated/Spring Return Valve, 1/4 in. NPT, 24VDC, 5/2. The media type is compressed air and the valve shows off various worthwhile traits such as being low power, high flow, and maintenance free. There is a fixed length manifold available. The product comes from the V61 Series.

Specifications:

  • V61 Series
  • Max Temperature: 122 F
  • Min Temperature: 14 F
  • Max PSI: 145
  • Min PSI: 29
  • Port Size: 1/4" NPT
  • Media: Compressed Air
  • Voltage DC: 24
