IPTCI UCP210-32 Two Bolt Cast Iron Standard Duty Pillow Block for 2 in. Shafts

Brand:
Mfr. Model #:
UCP210-32 IPTCI
KR Part #:
UCP21032
Weight:
6.80 lbs
Usually Ships in 2 Weeks
MSRP
$118.30
Now Only!
$73.94
Standard duty pillow block with a cast iron housing and a set screw lock. Use with 2" shafts. Mount with two 5/8" size bolts.
Conveyor & Tunnel

Conveyor & Tunnel




Technical Specifications

Bore: 2 inch

Product Description

UCP Series 2" Bore Pillow Block

The UCP210-32 is a standard duty pillow block with a cast iron housing, a high shaft height, and a set screw lock. This industrial pillow block is used with 2" diameter shafts.

Specifications:

  • 2" bore diameter
  • Cast iron housing
  • Ball type bearing insert - 52100 chrome steel
  • 2 bolt mount - size 5/8"
  • 2.25" on center
  • Wide inner race bearing
  • High shaft height
  • Set screw lock
  • Bearing Number: UC 210-32
  • Housing Number: P 210
  • Weight: 6.8 lbs.



Drawing Dimensions:

  • Dimension A: 8"
  • Dimension B: 2 1/4"
  • Dimension Bi: 2.0315"
  • Dimension d: 2" bore diameter
  • Dimension E: 6 1/4"
  • Dimension G: 15/16"
  • Dimension H: 2 1/4"
  • Dimension M: 1.2835"
  • Dimension N: .7480"
  • Dimension S1: 23/32"
  • Dimension S2: 15/16"
  • Dimension W: 4 33/64"
