CAT Pumps 1010 Brass Manifold Triplex Piston Pump - 13 GPM, 700 PSI
Brand:
Mfr. Model #:
1010
KR Part #:
PU1010
Weight:
30.00 lbs
GTIN:
814338021602
Availability:
3
Low Inventory Get It Today
Chrome plated brass manifold triplex piston pump with stainless steel valve assemblies, cylinders, and sleeves. 700 PSI, 13 GPM. Brackets not included!
NOTE: This pump does NOT come with oil
Technical Specifications
Crankcase Capacity: 40 oz.
Max GPM: 13
Max PSI: 700
Max Temperature: 160 degrees F
RPM: 900
Bore: 28.5 millimeter
Stroke: 28 millimeter
Shaft Diameter: 25 millimeter
Inlet Port: 1 inch
Product Description
Ten Frame Piston Pump with Brass Manifold
The CAT Pumps 1010 model is a three piston rod positive displacement, reciprocating piston pump. It has a chrome-plated brass manifold with stainless steel valve assemblies, cylinders, and sleeves. Its low RPM is designed for belt drive. The Uniflow design features a mechanically actuated inlet valve providing a continuous forward fluid flow and strong suction.
Dimensions: 17.28 x 11.42 x 6.30"
Specifications:
- Max Flow: 13 GPM
- Minimum Pressure: 100 PSI
- Maximum Pressure: 700 PSI
- Maximum Temperature: 160° Fahrenheit
- Inlet Port Size (1): 1" NPT
- Discharge Port Size (3): 3/4" NPT
- RPM: 900 RPM
- Drive Type: Belt
- Manifold Material: Brass
- Shaft Diameter: .984"
- Bore: 1.122"
- Stroke: 1.102
- Inlet Pressure Range: -8.5 to 40 PSI
- Weight: 34.6 lbs.
Features:
- Triplex Uniflow design provides continuous forward liquid flow for smooth operation.
- Wetted cups and floating pistons are lubricated and cooled by pumped liquid for long cup life.
- Mechanically actuated inlet valves give strong lift and easy prime.
- Oil bath crankcase assures optimum lubrication.
- 100% wetted seal design allows pumped liquid to cool and lubricate for longer life.
- Please note that this pump does NOT come with oil - find authentic CAT Pumps Oil here.
