Dema 463PS.3 Stainless Steel Mini Diaphragm Valve - 3/8in., 24V

Mfr. Model #:
KR Part #:
0.74 lbs
In Stock
Now Only!

This mini diaphragm valve releases the pressure on top of the diaphragm allowing incoming pressure to lift it off the large center port.

Prep 65

Prop 65


Technical Specifications

Max PSI: 125
Voltage AC: 24

Product Description

3/8" Valve with 24VAC Spade Coil

The valve features molded water resistant coil with spade connections, 303 investment cast stainless steel body, and an EPDM diaphragm. Bracket and cover included. When energized, the mini diaphragm valve can push from the top plug by kick-off spring and closes the pilot port.


  • Stainless steel
  • Normally closed
  • 3/8" size
  • EPDM diaphragm
  • 24VAC spade coil
  • 125 PSI maximum pressure
  • NSF Standard 61
