Mosmatic 34.885 Nickel Plated Brass High Flow 90 Degree DGE Rotary Union - 1 Inch NPTF, 4000 PSI, 30 RPM

Brand:
Mfr. Model #:
34.885
KR Part #:
SWM34885
Weight:
3.78 lbs
Availability:
2
Low Stock Warning
Add to Cart for Price
This is a rotary union made with nickel plated brass. This union engineered for pressures reaching 4000 PSI. Features a dual bearing system.



Product Description

High Flow Rotary Union

This rotary union is designed to operate with virtually no maintenance. Operates at a maximum pressure of 4000 PSI and 30 RPM. Swivel is crafted using nickel plated brass. Fits connections with a 1-inch NPTF threaded diameter. Used in high pressure hose reels and automatic car wash systems.

Specifications:

  • Pressure: 4000 PSI (27.5 MPA)
  • Temperature: 250°F
  • RPM Maximum: 30 RPM
  • Body: Brass, Nickel Plated
  • Inner Part: Stainless Steel
  • Seal: O-Ring NBR (Optional: EPDM Or FKM
  • Bearing: 1x Thrust Ball Bearing, 1x Radial Ball Bearing
  • Throughput: Ph 3-12
  • Medium: Filtered 10 Microns, Compressed Air (290 PSI)
  • Commonly used with PDQ systems

Features:

  • Maintenance Free
  • Sealed Stainless Steel Bearings
  • High Flow

Applications:

  • Automatic Car Wash Systems
  • High Pressure Hose Reels
  • High Flow
  • Low RPM
