Name: PDQ 03150019 Brass 1/2" Injector with External Adjustment Screw
Brand: PDQ
SKU: 03150019

Brand:

PDQ

Mfr. Model #:

03150019

KR Part #:

03150019

Weight:

1.26 lbs

Low Inventory Get It Today

Now Only!

$105.33

Frequent Questions

The 03150019 Chemical Injector from PDQ is an OEM part for select LaserWash automatic systems, used on the bridge of the systems. This injector is made of brass and has 1/2" NPT inlet/outlet ports and a 1/4" barb for the chemical tube. It has a Ryton metering knob and check valve core for increased chemical resistance, along with an external screw for easy flow rate adjustment. Includes tubing.

More Info...

Technical Specifications

Type: LaserWash ProTouch Tandem

Type: LaserWash ProTouch Icon

Type: LaserWash 360

Inlet Port: 1/2 inch

Outlet Port: 1/2 inch

Max PSI: 700

Product Description

Replacement 03150019 Injector for LaserWash System Bridge

The PDQ 03150019 Injector is an OEM replacement part for the bridge on a variety of LaserWash automatic car wash systems. This brass chemical injector has 1/2" NPT connection ports and a 1/4" barb for the chemical tube. It features a Ryton metering knob and check valve core for high chemical resistance. An external adjustment knob makes it easy to adapt water flow to the specific application. Tubing is included.

Item Details

Brass construction
1/2" FNPT x 1/2" MNPT ports
1/4" barb
Ryton metering knob (with screw) and check valve core
Chemical dilution adjusts with metering screw or metering tips (tips not included)
External adjusting screw for easy compensation to system variations
Efficiently adjusts to flow or pressure changes after installation
Allows system to operate at maximum performance level without a teardown
Metering knob assembly can be oriented in any direction for ease of access in tight spots
Tubing included
Flow rate @ 200 PSI: 5.7 to 19 GPM
Maximum 700 PSI (water at room temperature), 500 PSI (water at 150° Fahrenheit)
OEM part made by DEMA for PDQ
