General Pump ETB1809S17 Electric ETB Series Triplex Plunger Pump - 3.20 GPM, 2320 PSI, 1750 RPM
Brand:
Mfr. Model #:
ETB1809S17
KR Part #:
GPETB1809S17
Weight:
11.00 lbs
A triplex plunger pump with a forged brass manifold and ceramic plungers to deliver a longer life span. The solid, right-side mounted driveshaft measures 24mm. Delivers a maximum flow rate of 3.20 GPM.
Technical Specifications
Max GPM: 3.2
Max PSI: 2320
RPM: 1750
Max Temperature: 165 degrees F
Inlet Port: 1/2 inch
Outlet Port: 3/8 inch
Shaft Diameter: 24 millimeter
Bore: 18 millimeter
Stroke: 9.4 millimeter
Product Description
24 mm Solid Shaft Plunger Pump
The General Pump ETB1809S17 is an electric triplex plunger pump from the ETB series. It is built with a forged brass manifold to increase the durability of the pump's head. Plungers are made with solid ceramic to improved strength. Designed with a 24mm solid shaft, mounted on the right side. The pump is engineered to endure a maximum pressure of 2320 PSI, handles a maximum speed of 1750 RPM, and produces a flow rate of 3.20 GPM.Specifications:
- GPM: 3.20
- PSI: 2320
- RPM: 1750
- HP: 5.0 EBHP
- Maximum Inlet Pressure: 125 PSI
- Max. Inlet Vacuum: 3 ft. water (2.6 Hg) Flooded
- Plunger Bore: 0.708 in./18 mm
- Plunger Stroke: 0.370 in./9.4 mm
- Oil Capacity: 8.5 oz.
- Maximum Fluid Temperature: 165° F
- Inlet Port Thread: 1/2"-14 BSP-F
- Discharge Port Thread: 3/8"-19 BSP-F
- Shaft Diameter: 0.945"/24mm, Right Side
- Weight: 11.0 lbs.
- Dimensions: 8.0" x 7.4" x 4.7"
- Durable forged brass manifold
- Dust protection chamber
- Solid ceramic plungers
- Advanced plunger mounting system
- Valve cover for ease of service
- 24mm solid shaft, right side mounted
