General Pump ETB1809E175 Electric ETB Series Triplex Plunger Pump - 3.20 GPM, 2320 PSI, 1750 RPM
Brand:
Mfr. Model #:
ETB1809E175
KR Part #:
GPETB1809E175
Weight:
11.00 lbs
A triplex plunger pump with a forged brass manifold and ceramic plungers to deliver a longer life span. The NEMA 56C shaft measures 5/8". Delivers a maximum flow rate of 3.20 GPM.
Technical Specifications
Max GPM: 3.2
Max PSI: 2320
RPM: 1750
Max Temperature: 165 degrees F
Inlet Port: 1/2 inch
Outlet Port: 3/8 inch
Shaft Diameter: 5/8 inch
Bore: 18 millimeter
Stroke: 9.4 millimeter
Product Description
5/8" Hollow Shaft Plunger Pump
The General Pump ETB1809E175 is an electric triplex plunger pump from the ETB series. It is built with a forged brass manifold to increase the durability of the pump's head. Plungers are made with solid ceramic to improved strength. Designed with a 5/8" hollow shaft that meets NEMA 56C flange standards, mounted on the right side. The pump is engineered to endure a maximum pressure of 2320 PSI, handles a maximum speed of 1750 RPM, and produces a flow rate of 3.20 GPM.Specifications:
- GPM: 3.20
- PSI: 2320
- RPM: 1750
- HP: 3.6 EBHP
- Maximum Inlet Pressure: 125 PSI
- Max. Inlet Vacuum: 3 ft. water (2.6 Hg) Flooded
- Plunger Bore: 0.708 in./18 mm
- Plunger Stroke: 0.370 in./9.4 mm
- Oil Capacity: 8.5 oz.
- Maximum Fluid Temperature: 165° F
- Inlet Port Thread: 1/2"-14 BSP-F
- Discharge Port Thread: 3/8"-19 BSP-F
- Shaft Diameter: 5/8" Hollow, Right Side
- Weight: 11.0 lbs.
- Dimensions: 7.3" x 7.4" x 5.5"
- Durable forged brass manifold
- Dust protection chamber
- Solid ceramic plungers
- Advanced plunger mounting system
- Valve cover for ease of service
- NEMA 56C flange, 5/8" hollow shaft, right side mounted
