M12 _ 1 Inductive Sensor

Turck's NI5-G12-AN6X-H1141 is an inductive sensor is used as a contactless sensing device in car wash applications. Feature an M12 _ 1 threaded barrel with a maximum switching distance of 5-millimeters. Constructed with a yellow PA12-GF30 plastic material. Compatible with 10 - 30 VDC voltage electrical connections.

Specifications:

• Type: NI5-G12-AN6X-H1141
• ID: no. 4635793
• Rated Switching Distance: 5 mm
• Mounting Conditions: Non-flush
• Secured Operating Distance: _ (0.81 _ Sn) mm
• Correction Factors: St37 = 1; Al = 0.3; Stainless Steel = 0.7; Ms = 0.4
• Repeat Accuracy: _ 2 % of Full Scale
• Temperature Drift: _ ± 10 %
• Hysteresis: 3É15 %
• Ambient Temperature: -25É+70 °C
• Operating Voltage: 10É30 VDC
• Residual Ripple: _ 10 % Uss
• DC Rated Operational Current: _ 200 mA
• No-Load Current: _ 15 mA
• Residual Current: _ 0.1 mA
• Isolation Test Voltage: _ 0.5 kV
• Short-Circuit Protection: Yes / Cyclic
• Voltage Drop at Ie: _ 1.8 V
• Wire Breakage/Reverse Polarity Protection: Yes / Complete
• Output Function 3-wire, NO Contact, NPN
• Switching Frequency 1.5 kHz
• Design: Threaded Barrel, M12 _ 1
• Dimensions: 61 mm
• Housing Material: Metal, CuZn, Chrome-Plated
• Active Area: Material Plastic, PA12-GF30
• Max. Tightening Torque of Housing Nut: 10 Nm
• Electrical Connection Connector: M12 _ 1
• Vibration Resistance: 55 Hz (1 mm)
• Shock Resistance: 30 g (11 ms)
• Protection Class: IP67
• MTTF: 2283 Years acc. to SN 29500 (Ed. 99) 40°C
• Switching State LED, Yellow
