Fully Programmable Laundry Dispenser

The Hydro Systems 00-07660-720 Mercury TL700 Dispensing System is a 2-product unit for top-loading laundry applications. The Mercury TL700 brings together modern technology with a simple interface, and it has auto voltage sensing so either 115 ot 220 volt wiring can be connected to the single power input leads.

The long-life Mercury TL700 boasts spring loaded peristaltic pumps, a Quik-Klip mounting bracket, and simple 3-button programming. You can choose from four different operating modes for maximum flexibility in small OPL and Top Load washer laundry applications.

• 2 products
• Each pump operates at 6 ounces per minute

Features:

• Auto Formula Select- No need for formula selection at the dispenser when used with a fully programmable microprocessor washing machine.
• Stopwatch Style Programming- No need to convert time and ounces.
• Flush Capability- Flush logic and a flush output are available as a standard feature.
• Spring Loaded Spinners- Spring loaded spinners result in extended squeeze tube life.
• Remote Formula Selector- Allows the selection and activation of a formula from the selector box. No need to access the dispenser.
• Built-in Load Counter- Formula load counts are automatically logged, and can be reset.
• Quik-klip Mounting Bracket- A built-in level indicator helps insure a neat installation.
• Pre-wired- The Mercury LM-700 is pre-wired at the factory. There is no need to open the cabinet during normal installation.
• Auto-voltage Sensing Power Supply- No transformers required. A unique power sensing module allows connection to either 115 or 220 VAC main power.
• Quick Change Squeeze Tubes- Captive Thumb Screws on pump covers allow for quick "no tools" squeeze tube changes.
• Password Protected- A three digit PIN protects the programming from unauthorized access. The password PIN may be changed to a custom PIN via the programming menu. THERE IS NO COMMON BACK-DOOR PASSWORD.
• Splashproof Enclosure- The molded cabinet is fully gasketed to prevent moisture from entering the cabinet and attacking the electronics.


Four Operating Mode Options:

• Automatic Mode

• Push Button Mode

• Occurrence Mode

• Relay Mode
