Telemecanique XMLK300P2D23 OsiSense XM Pressure Transmitter Sensor - 300 PSI
Brand:
Mfr. Model #:
XMLK300P2D23
KR Part #:
STP3000
Weight:
0.24 lbs
GTIN:
338911904916
Availability:
4
Electronic pressure style transmitter. Part of the Telemecanique OsiSense XM line of sensors. Regulate fluid and steam pressure. 300 PSI, 1/4"-18 MNPT, 24VDC.
Technical Specifications
Max PSI: 300
Voltage DC: 24
Inlet Port: 1/4 inch
Product Description
300 PSI Pressure Style Sensor
The Telemecanique XMLK300P2D23 is part of the OsiSense XM series of sensors. This sensor is used to measure and regulate fluid and steam pressure. Commonly used with booster pumps in car wash systems.
Dimensions: 1.17" W x 1.17" H x 2.92" D
Main Specifications:
- OsiSense XM Series
- Pressure transmitter type sensor
- Electrical Circuit Type: Control circuit
- Pressure Sensor Size: 300 PSI
- Temperature Range: 32° to 176°
- Fluid Connection Type: 1/4" - 18 NPT (male)
- Electrical Connection: 1 male connector M12 4 pins
- Rated Supply Voltage: 24VDC
- Current Consumption: <20 mA
- Type of Output Signal: Analogue
- Weight: .24 lbs.
UPC:
- 00785901698449
