Dosatron PS6A138-4-NA Low-Pressure Modular Four Bay Dispenser System - 500:1-50:1
Brand:
Mfr. Model #:
PS6A138-4-NA
KR Part #:
PS6A138-4-NA
Weight:
20.00 lbs
Easy-installation four bay package with a Dosatron D14MZ10AFDII chemical dispenser and pre-plumbed solenoid valves. Mounted on a panel that can be quickly installed in your chemical room. Used with wax and presoak solutions. NOTE: Image shown is for illustrative purposes only. Your system will look slightly different depending on the amount of bays it's set up to service and if it includes air.
Made In The USA
Self Serve
DROP SHIP
Technical Specifications
Max PSI: 85
Max Temperature: 104 degrees F
Inlet Port: 3/4 inch
Voltage AC: 24
Min PSI: 4.3
Max GPM: 14
Type: Chemical Dispenser/Injector
Product Description
Panel Mounted 500:1-50:1 Chemical Dispensing Unit - Quad Bay
The Dosatron PS6A138-4-NA Panel System is a modular style chemical dispensing unit mounted on a wall panel. It's simple to install and has a small footprint in your chemical room. This package boasts a Dosatron D14MZ2VFDII chemical proportioner and pre-plumbed solenoid valves to control low-pressure lines in four self-serve car wash bays. Used for presoak and wax chemicals. Read more about the new Modular Low-Pressure Systems in our blog post about them!
Specifications:
- Max Temperature: 104° Fahrenheit
- Flow Rate: 0.05 GPM - 14 GPM
- Pressure: 4.3 PSI - 85 PSI
- 3/4" outlet for additional panel hookup
- 3/8" poly elbow for delivery to bays
- Polypropylene housing
- Hastelloy metal components
- Designed for four bays
- 24VAC voltage
- 500:1-50:1 dilution range
- Panel-mounted
- Made in the U.S.A.
Features:
- Dispenser operates on only water flow - only solenoids require electricity
- Eliminates Venturi premix tanks - saves space
- No need for air diaphragm pumps - less air compressor use
- Get rid of messy Venturi metering tips that clog
Typical Applications Based on Dilution Requirement:
- Presoaks
- Waxes
