Dema 900.DS4 Compressed Air and 120V Power Wall Mount Foamer for Concentrates - 2 Nozzle Assemblies, 2 Spray Tips Included

Mfr. Model #:
KR Part #:
30.00 lbs
Usually Ships in 2 Weeks
Add to Cart for Price
Stainless steel foam producing assembly in a fiberglass housing. Includes control box and two stainless steel nozzle assemblies with ST80100 spray tips, two tee fittings, and 100' of tubing. Foam pattern of up to 8x4 ft. at each nozzle.
Prep 65

Prop 65

120 Volts

120 Volts


Product Description

Air and Electric Foam Sprayer

The Dema 900.DS4.2 is a complete foaming system including a control box, 100' tubing, and two ST80100 spray tips. This foamer uses concentrated chemicals and water to produce thick foam that adheres to surfaces long enough for effective cleaning. The included spray tips are stainless steel twin line nozzles capable of covering up to a 8' by 4' area each, for the potential to cover an 8' x 8' or 16' x 4' area at once. The control box can be mounted up to 150' away from the spray nozzle assembly. Powered by compressed air and 120 volt electricity.

Specifications and Features:

  • Draws from concentrated chemicals
  • Requires 10-100 PSI water pressure - backflow prevention is required
  • Requires 120 VAC at 60 Hz, 2 amps (GFCI protected outlet)
  • 38:1 to 183:1 dilution ratio range
  • 40° to 100° Fahrenheit liquid temperature range
  • 8' clear hose suction line - 1.4" inside diameter
  • 2 GPM flow rate
  • 8' x 4' coverage area per nozzle
  • Santoprene seals
  • Stainless steel twin line spray nozzle included
  • Control box can support up to three nozzle assemblies (only two included)
  • Designed for use with 1/2" outside diameter tubing between control box and nozzle
  • Air regulator is factory set at 50 psi. Operating range is 40 to 80 PSI with 5 to 10 CFM.
