XS6 Output Sensor

The Telemecanique OsiSense XS618B1MAU20 inductive proximity sensor is designed for general use and offers a discrete output signal. This sensor has a fixed body and nickel plated brass enclosure with an 8mm (0.31") nominal sensing distance. Thanks to the IP67/IP69K rating, it's great for use in a variety of wet environments and applications including assembly machines, robotics, machining tools, packaging operations, conveyors, or food and beverage production.

This is a clearance item with limited inventory. All sales final - no returns.

This sensor is compatible with:

• Kleen-Rite part # STP130 PVC straight cordset (manufacturer model # XZCPV1865L10)
• Kleen-Rite part # STP122 PVC 90 degree elbow cable (manufacturer model # XZCPV1865L5)
• Kleen-Rite part # STP120 PUR straight cable (manufacturer model # XZCP1865L2)
• Kleen-Rite part # STP125 PUR 90 degree elbow cable (manufacturer model # XZCP1965L2)

Length: 73mm (2.87")


• XS6 M18 sensor
• OxiSense XS line
• 8mm nominal sensing distance with frontal detection face
• 1 yellow status LED
• 2-wire design

• 24 AC/DC electrical connection

• 1/2"20 UNF 3-pin electrical connector
• M18 x 1 ISO thread - 52mm (2.05") total threaded length)
• Ambient air temperature: -13°F to 158°F
• CSA and UL certified, CE marked

• Telemecanique part #: XS618B1MAU20

• Weight: 0.36 lbs.
