PNP Output Sensor

The Telemecanique OsiSense XS530B1PAM12 inductive proximity sensor is designed for general use and offers a discrete output signal. This sensor has a fixed body and nickel plated brass enclosure with a 10mm (0.39") nominal sensing distance. Thanks to the IP67/IP69K rating, it's great for use in a variety of wet environments and applications including assembly machines, robotics, machining tools, packaging operations, conveyors, or food and beverage production.

This sensor is compatible with:

• Kleen-Rite part # STP135 PVC straight cordset (manufacturer model # XZCPV1141L2)

Dimensions: 55mm x 30mm (2.16" x 1.18")

• XS5 M30 sensor
• OxiSense XS line
• 10mm nominal sensing distance with frontal detection face
• 1 yellow status LED
• 3-wire design
• PNP discrete output on DC circuit

• 24 VDC electrical connection with reverse polarity protection required
• 4 pin M12 male electrical connector
• M30 x 1.5 ISO thread - 32mm (1.26") total threaded length)
• Ambient air temperature: -13°F to 158°F
• CSA and UL certified

• Telemecanique part #: XS530B1PAM12

• Weight: 0.32 lbs.
