Parker 12 C6X-S Triple-Lok 37 Degree Flare JIC Tube Fitting - 5000 PSI, 3/4 Inch Male 37 Degree Flare, 3/4 Inch Female 37 Degree Flare Swivel

Brand:
Mfr. Model #:
12 C6X-S
KR Part #:
PLF583S
Weight:
0.55 lbs
Usually Ships in 2 Weeks
MSRP
$40.03
Now Only!
$19.24
A 90 degree elbow fitting with 3/4-inch 37 degree flare JIC male and female connections. Provides a leak-free metal-to-metal connection. Tolerates a maximum pressure of 5000 PSI.



Technical Specifications

Max PSI: 5000
Inlet Port: 3/4 inch
Outlet Port: 3/4 inch

Product Description

90° Elbow Triple Lok 37° Flare Adaptor

The Parker 12 C6X-S is a elbow fitting with male and female 37° flare connections with 3/4 inch diameters. JIC tube fittings provide a metal-to-metal seal for tolerating high pressures and deliver leak-free connections. Handles a maximum pressure of 5000 PSI. Made with steel for durability. Designed to meet SAE J514 and ISO 8434-2 requirements.


Specifications:
  • Connection Type: 37° Flare, Tube to Tube
  • Specifications Met: SAE J514
  • Maximum Dynamic Pressure: 5000 PSI
  • Shape: 90° Elbow
  • Connection 1 Size: Male 37° Flare
  • Connection 1 Tube Outside Diameter: 3/4 inch, 18, 20 mm
  • Connection 2 Size: Female 37° Flare Swivel
  • Connection 2 Tube Outside Diameter: 3/4 inch, 18, 20 mm
  • Body Material: Steel
  • Features/Benefits:
  • Compact design
  • Low assembly torque
  • High temperature resistance
  • High pressure capability
  • Dynamic pressure up to 5,000
  • Works with a wide variety of tubes and hoses
  • Steel fittings substantially exceeded the SAE corrosion requirements of 72 hours without red rust, lasting up to 1,000 as found by an independent test facility.  This enhanced performance provides customers with a competitive advantage through extended equipment life, leading to increased revenues and reduced warranty costs.
  • Stainless Steel nuts have a coating to prevent galling.
