Sterling DH0034PCA Nema Premium Efficient Motor 3 HP, 3 Phase, 230/460V

Brand:
Mfr. Model #:
DH0034PCA
KR Part #:
MSE3000
Weight:
82.00 lbs
Out of Stock - Pre-Order Now
MSRP
$1,510.25
Now Only!
$764.50
Nema Premium Sterling motor for car wash facilities.
Freight Only

Freight Only




Technical Specifications

Voltage AC: 230/460
Amps: 7.8
Horsepower: 3
Phase: Three

Product Description

Electric Motor

A reliable, cost-effective motor for your wash facility. Features Premium Efficiency for the best performance possible! Constructed with sturdy rolled steel for long-lasting service life.

Features:

  • Premium Efficient
  • Rolled steel frame and cast iron end brackets
  • Sterli-seal washdown duty
  • Class 'F' insulation
    •  1.15 service factor
  • Ideal for 208 volt operation
  • C-face supplied with internally locked drive end bearing

Specifications:

  • Horsepower: 3 HP
  • RPM: 1800 RPM, 1760 RPM (full load)
  • 3 Phase
  • Frequency: 60
  • Voltage: 230/460V
  • Frame Size: 182TC
  • C-Face Footless Mounting
  • TEFC Enclosure
  • Amps: 7.8/3.9, 62/31 (locked)
  • Efficiency:
    • 100%: 89.5
    • 75%: 74.5
    • 50%: 63.5
  •  Power Factor:
    • 100%: 81.3
    • 75%: 74.5
    • 50%: 63.5
  • Full Load Torque: 8.95 lb. / sq. ft.
  • Locked Rotor Torque: 200% of Full Load
  • Breakdown Torque: 320% of Full Load
  • Brake Torque: 0 ft. lb.
  • Premium Efficiency Type
  • Rolled Steel Construction
