CAT 7014 Pressure Regulator - 10 GPM, 4000 PSI
Brand:
Mfr. Model #:
7014
KR Part #:
PU7014
Weight:
4.00 lbs
Out of stock - Pre-Order Now!
Manuals
This 10 GPM regulator has a flow-through design for easy plumbing into the discharge line or directly onto the discharge head.
Technical Specifications
Inlet Port: 1/2 inch
Max GPM: 10
Max PSI: 4000
Max Temperature: 240 degrees F
Product Description
High Pressure Regulator
This regulator is designed for single or multiple pump, weep, or multi-nozzle systems. It comes with standard FPM elastomers for compatibility with liquids and temperatures up to 240 degrees Fahrenheit. For optimum performance, 5-10% by-pass is needed.
Other features include a conical piston and seat for smooth flow that reduces wear and tear. Thanks to the high velocity design, it provides consistent pressure for multiple pump or shut-off gun installations. Also, the adjusting nut offers easy calibrated pressure adjustments.
Dimensions: 7.5" x 1.88"
- Pressure range: 2000 - 4000 PSI
- Quick return to full pressure when all guns and nozzles resume operation
