Turck NI15-S30-AZ3X Plastic Threaded Inductive Barrel Sensor- 15 MM, 2 M Cable
Brand:
Mfr. Model #:
NI15-S30-AZ3X
KR Part #:
TPS1200
Weight:
0.25 lbs
This is a PA12_GF30 plastic housed inductive sensor. Designed to reach a maximum distance of 15 mm. Rated for IP 67 protection standards.
Note: Includes a 2 M cable.
Product Description
M30 x 1.5 Inductive Sensor
Turck's NI15-S30-AZ3X inductive sensor is used as a contactless and wear-free way to detect objects at car washes. Sensing distance reaches a maximum of 10-millimeters. Constructed with a PA12_GF30 plastic housing. Compatible with 20-250 VAC / 10-300 VDC voltage power connections.
Specifications:
- Design: Threaded barrel
- Construction Size: M30 x 1.5
- Rated Switching Distance: 15 mm
- Mounting Conditions: Non-flush
- Operating Voltage: 20É250 VAC / 10É300 VDC
- Output Function: NO contact, 2-wire
- Electrical Connection: Cable
- Cable Length: 2.0 m
- Housing Material: Plastic, PA12-GF30
- Ambient Temperature: -25É+70 °C
- Protection Class: IP67
