Motor Operated Pump

Flojet's R3B21502A is a three-chamber diaphragm pump designed for road rollers and includes an integrated 12 VDC electric permanent magnet motor. Engineered with an external bypass system to protect the pump from excessive back pressure. Features the ability to run and self-prime when dry without damaging the critical components of the pump. Operates at a maximum pressure of 50 PSI.

Specifications:

• Pump Design: Motor Operated 3 Chamber Diaphragm

• Motor: Permanent Magnet DC

• Voltage: 12V DC

• Pump Head: Glass Filled Nylon

• Amp Draw: 8.5

• Max Running Pressure: 50 PSI

• Bypass PSI: 50

• Diaphragm: Santoprene

• Check Valve: Viton

• Max. Flow Rate @ 30 PSI: 1.25 GPM

• Fittings: 1/2" HB ST

• Max. Liquid Temperature: 4 - Min, 71 - Max °C, 40 - Min, 160 - Max °F

• Duty Cycle: Continuous

• Weight: 7.0lb

• Size: L 9.53" x W 4.45" x H 4.24"

• Certifications: CE, RoHS, C-Tick, E-Mark

• Port Size Inlet / Outlet: Standard 1/2" HB Straight


Features:

• Highest flow rates for their size

• Plug-in ports for easy installation and servicing

• Can be mounted easily anywhere with functional mounting platforms & simple connections - fit it
• anywhere and plumb up

• External bypass protects the pump from back pressure

• Low cost, low maintenance modular design means a trouble-free service life

• Spare parts & accessories are readily available & easy to install

• Self-priming even when dry

• Dry vertical lift from 6 ft. up to 10 ft.

• Can run dry without damage


Applications:

• Ride-on Road Rollers with knock-down bar

• Ride-on Road Rollers with articulating-swivel

• Vibratory Road Rollers

• Pneumatic-tyre Road Rollers

• Tractor mounted and powered Road Rollers
