The Banner Sensors QS303E is a high performing opposed mode emitter designed to operate effectively at long ranges. It features a maximum sensing distance of 60000 mm or 196 feet. It is encapsulated with a thermoplastic housing the is equipped with an M30 style mount. Compatible with 12-250VDC or 24-250VAC electrical connections. Lead cable measures 2 inches.
Specifications:
Cable Length (m): 2 (6.5 ft.)
Sensing Beam: Infrared LED
Power: AC/DC Universal
Sensing Mode (General): Opposed
Sensing Mode (Detailed): Emitter
Housing Style: Rectangular w/M30 Mount
Primary Housing Material: Thermoplastic
Max Sensing Distance (mm): 60000 (196 ft.)
Power Supply/Supply Voltage: 12-250 V dc or 24-250 V ac
Connection: Cable
Quick Disconnect Type: No QD
Operation: N/A
Min Op. Temp. (°C): -20
Max Op. Temp. (°C): 70
Output response time (ms): 15
Delay at Power-up (ms): 100
Number of Pins: 2
NEMA Rating: NEMA 6
IP Rating: IP67
Max Op. Relative Humidity [%]: 95% @ 50°C
Lens Material: Acrylic
Adjustments: N/A
Barrel Diameter (mm): 30
Indicator: LEDs
Opposed Mode Emitter/Receiver: Emitter
Timing (Hold/Delay): No
Encapsulated: No
Hazardous Area: No
Audible: No
Chemical Resistant: No
Quick Disconnect: No
DeviceNet: No
IO Link: No
Applications:
Vehicle Profiling (In-Bay Automatic/Rollover): Accurately determines vehicle front and back bumper position. Allows gantry to travel minimal distance to ensure a quick, close wash. Helps prevent vehicle damage. Most powerful "burn-thru" sensor, without requiring an external amplifier.
Entry/Exit Doors (In-Bay Automatic/Rollover and Conveyorized Tunnel): Verifies that a vehicle has either entered or exited the car wash. Prevents doors from closing on the vehicle. Dual sensors may be used: one inside and one outside.
Soap and Rinse Activation (Conveyorized Tunnel): Detects front of vehicle and triggers soap/foam jets and triggers rinse cycle. Remains active while vehicle is blocking the sensor.
Dryer Activation (Conveyorized Tunnel): Triggers dryers to turn on and off. May control dryer distance from vehicle.
