Dosmatic 112600 MiniDos 12 - 1 Percent Injector - 12 GPM

Brand:
Mfr. Model #:
HYD112600
KR Part #:
DM112600
Weight:
4.15 lbs
Out of Stock - Pre-Order Now
MSRP
$556.89
Now Only!
$397.79
The Dosmatic MiniDos low-mid flow, fluid (water)-driven proportional injectors offer a low cost alternative to traditional, non-electric technology. These injectors are compact and offer the widest range of injection ratios.



Product Description

12 GPM 1% MiniDos Dispenser

Unlike traditional electric pumps, the MiniDos injectors eliminate the need for electricity and can operate in remote areas. They are easy to install and maintain; making them ideal for low-mid-flow injection applications. Now available for Peracetic Acid (PAA).

Get precise additive injection! Proportional positive displacement ensures that just the right amount of chemical is injected each and every time, regardless of pressure and flow. An adjustable ratio sleeve allows you to change the percentages quickly and easily to meet your injection needs. Chemical costs are reduced because of less waste in the injection process.

The MiniDos is safe and cost effective. The non-electric Dosmatic injectors reduce the liability risk concerns associated with traditional electrical pumps. The Dosmatic injectors use a patented one-way gasket. Only the mixing chamber and the lower end are exposed to the chemical. This prolongs the life of the motor, and the innovative mixing chamber design also ensures a thorough and precise mixing of the fluid and injected chemical. Typically, non-electric injectors reduce start-up costs by 30-60% over traditional electric injectors.

Dosatron MiniDos has a durable body and is super easy to operate. The body construction has engineered proprietary composite material greater than PVDF, which withstands severe weather, the chemicals used for injection, and higher operating pressures. A built-in On/Off bypass allows you to stop the injection but not the system, and an optional remote discharge is available for the whole product line.
Specifications:
  • Connections: 3/4" NPT
  • Maximum Temp: 100° F
  • Minimum Temp: 34° F
  • Weight: 4.5 lbs
  • Adjustable injection ratios

The MiniDos Injector Series can be used for:

  • Food processing treatments where disinfecting and surface cleaning are needed, such as bottle line cleaning, deodorizing seafood ice displays, ice making sanitation.
  • Circuit Board manufacturing, used in developing, acid cleaning, plus soluble and die-casting processes.
  • Horticulture treatments, to dispense fertilizers, pesticides, herbicides, fungicides, acids and disinfectants.
  • Metal processing and parts wash, to dispense coolants, oils, solvents, cutting fluids, soaps.
  • Printing treatments, used in pressroom solutions, flexo cleaning and reverse osmosis/water hardening.
  • Sanitation & hygiene treatments for clean water treatment, solid and wastewater treatment, biosanitation, slaughter plants, swine and poultry houses, and the stabilization of coal dust within mining operations
  • Specialty applications, such as asphalt treatment, water jet cleaning, concrete treatment, and timber treatment.
  • Pest control treatments, to provide accurate chemical dispensing with minimal waste in applications like pesticides, misting systems, panel systems termiticides, spray trucks and vector control.
  • Vehicle wash treatments, for the accurate dispensing of soaps, polishes, drying agents, and triple foam.
  • Water treatment applications that inject chemicals into residential and industrial water supplies.
