PN Series pumps are constructed with fiberglass reinforced thermoplastic body that provides total corrosion resistance and high resistance to abrasion. The jet has corrosion-resistant polypropylene nozzle and venturi. Features a precision-molded impeller for perfect balance, ultra-smooth for highest performance and efficiency. Polypropylene diffuser allows pump to prime faster, handle more air.

The heavy duty motor features stainless steel shaft and dual heavy-duty ball bearings that are shielded and permanently lubricated. These bearingshave been extensively tested to ensure extended life and smooth, quiet operation. Dual voltage motors are shipped at the 230-volt setting. The pumps are also pre-set to 30-50 PSI which allows for cut-in pressure adjustments. Easy plug removal and access for ease of service in the new nozzle design, and the new drain plug is bottom-mounted for easy draining and winterization.
Specifications:

• Maximum Temperature: 122 degrees F
• Max.Pressure: 78 PSI
• 3/4 Horsepower
• Liquid Temp: 140 degrees F
• Inlet: 1 1/4"
• Discharge: 1"
• 115/230V
